Gallery

Oil pipe heat shrinker

For use in the oil industry we pack and ship large specialist equipment.

This was for export to the Middle East.

Pilot seat case with sliding internal base frame

We regularly design and build specialist cases for transportation of aircraft spares and equipment. Pictured here is a case built to carry a pilot seat incorporating a sliding seat base frame.

Solar powered computers with lithium battery back up

These were packed for shipment to Nigeria, classed as hazardous due to the lithium battery content

Euro Copter EC135

Barrier Foiled Packing

This item is being 'barrier foiled' you can see the procedure from the pictures, they are fully enclosed by special heat sealed foil bags the air is then vacuumed out, which will leave a watertight hermetically sealed package.

Conveyor belt for exhibition use

We were asked to design a case to incorporate a ramp system for easy unpacking at exhibition venues.

This was accomplished by utilising the internal end of the packing case to incorporate the ramp runners. This conveyor was blocked as it was on wheels and we used ratchets to secure the machine in place.

Our design team incorporated a ramp

Ramp and fixing points shown

Completed case ready for shipment

Polished Stainless Steel Lawn Stanchions

Our client tasked us with designing a method to transfer three hundred 65cm long polished stainless steel stanchions with lawn spikes. It was imperative that they didn?t touch in transit as they were polished stainless steel.

Our designers came up with the solution by splitting the loads into three cases taking one hundred stanchions each. Each stanchion was countersunk into two retaining shelves, the internal lid was mounted with inch thick foam. The finished job incorporated drilling 600 holes!
